SPEC No. JEPD-0087-00
For Reference Only
16-2 Cleaning
16-2-1 Please clean the products to remove flux from them using the dipping, boiling, and vapor methods in isopropyl
alcohol for up to 5 minutes. Please inform us if you are to use aqueous or semi-aqueous cleaning or another
methods.
Do not use ultrasonic cleaning as semiconductor devices on the products, may be damaged by resonance.
16-2-2 After cleaning, please dry the products thoroughly. If you touch the products that have not been dried enough,
you must take care because the products markings may thin or blur.
Do not measure electrical characteristics, until the products are completely dry.
16-2-3 If you use no-clean flux and do not clean our products, you must confirm the reliability of the products fully in
advance.
16-3 Storage
16-3-1 Please store the products in a room where the temperature/humidity is stable and direct sunlight does not
enter Use the products within 6 months after delivery.
Avoid damp heated places or such places where there are large temperature changes, as water may condense
on the products, and the quality of characteristics may be reduced and/or the solderability may be degraded. If
you must store the products for a long time (more than 1 year), use caution because the products may degrade
in solderability and/or corrode.
Please confirm the solderability and characteristics for the products regularly.
16-3-2 Please do not store the products in places such as: A dusty place, a place exposed directly to sea breeze, or in an
atmosphere containing corrosive gas (Cl 2 , NH 3 , SO 2 , NO X and so on).
16-4 Operational Environment and Operational Conditions
16-4-1 Operational Environment
The products are not waterproof, chemical-proof or corrosion-proof.
In order to prevent leakage of electricity and abnormal temperature increase of the products, do not use the
products under the following circumstances:
(1) in an atmosphere containing corrosive gas (Cl 2 , NH 3 , SO 2 , NO X and so on)
(2) in a dusty place
(3) in a place exposed to direct sunlight
(4) in such a place where water splashes or in such a humid place where water condenses
(5) in a place exposed to sea breeze
(6) in any other places similar to the above (1) through (5)
16-4-2 Operational Conditions
Please use the products within specified values (power supply, temperature, input, output and load condition,
and so on). As the input voltage may drop due to impedance, please make sure that the input voltage is
included in specified values.
If you use the products outside of the specified values, it may break the products, reduce the quality, and even if
the products can endure the condition for short time, it may cause degradation of reliability.
16-4-3 Note Prior to Use
If you apply high static electricity, over rated voltage or reverse voltage to the products, defects may be caused
in the products or the reliability degrade. Please avoid the following conditions:
(1) over rating power supply, reverse power supply or inadequate connection of 0V(DC) line
(2) electrostatic discharge from production line and/or operator
(3) electrified product from electrostatic induction
Do not allow any excessive mechanical shock.
If the products are dropped on the floor, etc., a crack to the core of inductors and monolithic ceramic capacitors
may occur. Do not allow a strong shock such as a drop in handling.
